Description
Versatile Touch Applications
Whether used as a check-in kiosk at reception, as a collaboration station with co-workers and colleagues at the office, or as a touch podium for front-facing teaching, this sleek and slim touch display seamlessly integrates into your workflow for boosted efficiency and productivity.
Efficient Multitasking
With advanced DisplayPort Multi-Stream technology and support for up to 4-screen daisy chaining*, this display can transform into the ultimate touch screen workstation—in mirror and extended modes – for increased productivity. *up to 4 with a PC; up to 3 with a laptop
Touch Annotation for Presentations
An included stylus pen easily attaches to the magnetic base of the display, and allows you to draw, write notes, or perform other detailed tasks that require more accuracy than your fingertips alone. The pen is especially useful during presentations when the TD2455 is attached to a projector.
Accurate yet Smooth Touch Experience
Powered by in-cell touch technology, the TD2455 offers sensitive yet smooth touch response for detailed content editing with fingertips or the touch pen.
Quickly Start Your Work
The latest USB Type-C input transforms this display into a powerful hub by enabling easy connectivity to PC, laptop, and Chrome systems. In addition, it delivers charging power, video, and audio over a single cable.
Comfortable Working Angles
Designed with an ergonomically advanced dual-hinge stand, this display can be tilted and adjusted to deliver a more comfortable user experience.
Incredible Images, Sleek Design
With high-performance in-cell touch technology, this display provides smooth and responsive touch tracking, along with amazing screen performance, within a sleek and bezel-less design.
Minimal Design Concept
The ergonomic stand features an integrated client mount for quick installation of optional mini PC mount on the back of the display. Cable management features also keep your workspace neat.
Specs
| Display Size (in.) | 24 |
| Viewable Area (in.) | 23.8 |
| Panel Type | IPS Technology |
| Resolution | 1920 x 1080 |
| Resolution Type | FHD (Full HD) |
| Static Contrast Ratio | 1,000:1 (typ) |
| Dynamic Contrast Ratio | 50M:1 |
| Light Source | LED |
| Brightness (cd/m²) | 250 (typ) |
| Colors | 16.7M |
| Color Space Support | 8 bit (6 bit + Hi-FRC) |
| Aspect Ratio | 16:9 |
| Response Time (Typical GTG) | 6ms |
| Response Time (GTG w/OD) | 6ms |
| Viewing Angles | 178º horizontal, 178º vertical |
| Backlight Life (Hours) | 30,000 Hrs (Min) |
| Curvature | Flat |
| Refresh Rate (Hz) | 60 |
| Blue Light Filter | Yes |
| Flicker-Free | Yes |
| Color Gamut | NTSC: 72% size (Typ), sRGB: 104% size (Typ) |
| Pixel Size (mm) | 0.275 (H) x 0.275 (V) |
| Touch Screen | Projected Capacitive, 10-point multi-touch |
| Surface Treatment | Anti-Glare, Hard Coating (3H) |
| PC Resolution (max) | 1920×1080 |
| Mac® Resolution (max) | 1920×1080 |
| PC Operating System | Windows 7/8/8.1/10/11 certified; macOS tested |
| Mac® Resolution (min) | 1920×1080 |
| USB 3.2 Type A Down Stream | 2 |
| USB 3.2 Type B Up Stream | 1 |
| USB 3.2 Type C Up Stream | 1 (DisplayPort Alt mode, 60W power charger) |
| 3.5mm Audio Out | 1 |
| HDMI 1.4 | 1 |
| DisplayPort | 1 |
| DisplayPort Out | 1 |
| Power in | 3-pin Socket (IEC C14 / CEE22) |
| Internal Speakers | 2Watts x2 |
| Eco Mode (Conserve) | 9.7W |
| Eco Mode (optimized) | 12.8W |
| Consumption (typical) | 17.9W |
| Consumption (max) | 20.4W |
| Voltage | AC 100-240V |
| Stand-by | 0.3W |
| Power Supply | Internal Power Supply |
| Kensington Lock Slot | 1 |
| Physical Controls | Key 1 (eye), Key 2, Key 3, Key 4, Key 5, Key 6 (power) |
| On-Screen Display | Input Select, Audio Adjust, ViewMode, Color Adjust, Manual Image Adjust, Setup Menu |
| Temperature | 32°F to 104°F (0°C to 40°C) |
| Humidity (non-condensing) | 20% to 90% |
| VESA Compatible | 100 x 100 mm |
| Frequency Horizontal | 15 ~ 82KHz |
| Frequency Vertical | 50 ~ 75Hz |
| Digital Sync | TMDS – HDMI (v1.4), PCI-E – DisplayPort (v1.2), Micro-Packet – Type C |
| Ergonomics | |
|---|---|
| Tilt (Forward/Back) | -5º / 60º |
