Description
|
1.
USB-C® 3.2 Gen 1
|
8.
HDMI® 2.1 TMDS
|
|
2.
USB 3.2 Gen 2 (Always On and fast charge)
|
9.
USB 3.2 Gen 1
|
|
3.
USB 3.2 Gen 2
|
10.
DisplayPort™ 1.4
|
|
4.
Headphone / microphone combo jack (3.5mm)
|
11.
Power connector
|
|
5.
Ethernet (RJ-45)
|
12.
Punch out port 1*
|
|
6.
2x USB 3.2 Gen 2
|
13.
Punch out port 2*
|
|
7.
1x USB 2.0 (with smart power-on feature)
|
Specs
| PERFORMANCE | |
| Processor |
Intel® Core™ i5-13400T, 10C (6P + 4E) / 16T, P-core 1.3 / 4.4GHz, E-core 1.0 / 3.0GHz, 20MB
|
| Graphics |
Integrated Intel® UHD Graphics 730
|
| Chipset |
Intel® Q670 chipset
|
| Memory |
1x 8GB SO-DIMM DDR4-3200
|
| Memory Slots |
Two DDR4 SO-DIMM slots, dual-channel capable
|
|
Max Memory
|
Up to 64GB DDR4-3200
|
| Storage |
256GB SSD M.2 2280 PCIe® 4.0×4 NVMe® Opal 2.0
|
|
Storage Support
|
Up to two drives, 1x 2.5″ HDD + 1x M.2 SSD • 2.5″ HDD up to 1TB • M.2 SSD up to 2TB
|
| Card Reader |
No card reader
|
| Optical |
None
|
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC256VB codec
|
| Speakers |
2Wx1
|
|
Power Supply
|
90W 89% Adapter
|
| Keyboard |
USB Traditional Keyboard, Black, English
|
| Mouse |
USB Calliope Mouse, Black
|
| Optional Bay |
None
|
| Expansion Slots |
Two M.2 slots (one for WLAN, one for SSD)
|
| Case Color |
Black
|
| Stand |
Vertical Stand
|
| Adapter Cage |
None
|
| Toolless Chassis Screw |
None
|
| Dust Filter |
None
|
| Mounting |
None
|
| IO Box |
No IO box
|
| Form Factor |
Tiny (1L)
|
|
Dimensions (WxDxH)
|
179 x 182.9 x 36.5 mm with rubber feet (7.05 x 7.2 x 1.44 inches with rubber feet)
|
|
Weight
|
Around 1.25 kg (2.76 lbs)
|
| CONNECTIVITY | |
| Ethernet |
Integrated 100/1000M
|
|
WLAN + Bluetooth
|
Intel® Wi-Fi® 6E AX211, 11ax 2×2 + BT5.1, vPro®
|
| Front Ports |
|
| Optional Front Ports (configured) |
None
|
| Rear Ports |
|
| Optional Rear Ports (configured) |
DP
|
| Monitor Cable |
None
|
| SECURITY & PRIVACY | |
| Security Chip |
Discrete TPM 2.0, TCG certified
|
| Fingerprint Reader |
No fingerprint reader
|
| Physical Locks |
Kensington® Security Slot™, 3 x 7 mm
|
| Kensington Cable Lock |
None
|
| Chassis Intrusion Switch |
Chassis Intrusion Switch
|
| MANAGEABILITY | |
| System Management |
Non-vPro®
|
| SERVICE | |
| Base Warranty |
3-year, Onsite
|
| Included Upgrade |
None
|
| CERTIFICATIONS | |
|
Green Certifications
|
|
| Other Certifications |
TÜV Rheinland® Low Noise
|
| Mil-Spec Test |
MIL-STD-810H military test passed (Low Pressure [Altitude], High Temperature, Low Temperature, Humidity, Sand and Dust, Vibration, Shock, Solar Radiation, Contamination by Fluids, Salt Fog, Temperature Shock)
|
| SOFTWARE | |
| Operating System |
Windows® 11 Pro, English
|
| Bundled Software |
None
|
