Thermaltake F31 MT /w Window CA-1E3-00M1WN-03

$189.95

Thermaltake Suppressor F31 TG Series ATX Mid-Tower Case w/Windows No PS Retail CA-1E3-00M1WN-03

Housing the perfect balance in leading-edge sound reduction and cooling expansion, gain the perfect weapon for silent operation with unique sound dampening panels.

Regular Stock. Please contact our sales at 780-481-8855 to get current availability. Holds limited to 24 hours maximum.

SKU: CA1TH1CA2037 Categories: , Tag:

Description

Suppressor F31 Window ATX Mid Tower Chassis

The Suppressor F31 Window mid-tower chassis is the new addition to the Suppressor Series to the Thermaltake case line. Featuring the first chassis with 250mm wide and leading-edge sound reduction panels on all sides, expand your cooling options with removable panels for the perfect balance in silent operation and cooling performance. Supporting a range of motherboard platforms from Mini ITX to ATX solutions, unrivaled liquid cooling expansion and expandability for all high-end GPU solutions users can expect an enthusiast built design they can trust.

Tt LCS Certified

Tt LCS Certified is a Thermaltake exclusive certification applied to only products that pass the design and hardcore enthusiasts standards that a true LCS chassis should be held to. The Tt LCS certification was created so that we at Thermaltake can designate to all power users which chassis have been tested to be best compatible with extreme liquid cooling configurations to ensure you get the best performance from the best features and fitment.

Tool-Free Installation

Innovative 5.25” and 3.5” tool-free drive bay design minimizes installation/removal with hidden drive bays on the back panel to provide a clean look and improved expansion for liquid cooling components. The “2 + 3” drive bay with modular drive racks allows multiple SSD/HDD devices for improved storage capacity.

Fully Modular Design

With removable “2 + 3” drive racks, gain more for custom cooling components to freely interchange SSD/HDD cage sections for maximum interior space. Take advantage to include high-end, maximum capacity, cooling allotment without the reduction of GPU length limitations when incorporating liquid cooling expansion for the ultimate in cooling performance.

*Hidden drive bay allows expandability for more liquid cooling and still allows data drive mounting for a clean look. Cable management with maximum 50mm in width.

Dust Reduction

Super fine fan filters with excellent protection and reduction against dirt and dust on the top, inside the front-side panel, and at the bottom. Magnetic fan filter on the top simply attach the filter for dust filtration.

Handy I/O Ports

Design with convenience and cleanness in mind, Suppressor F31 Window has built in dual USB 3.0 and USB2.0, a HD audio connector, power, and reset button, grants a direct and easy access for external devices.



Modular Sound-Damping Design

Built-in sound-damping panels incorporated the top, front, and side panels of the Suppressor F31 chassis to reinforce noise reduction for silent operation. Optimizing cooling performance with removable mounted top panels to expand cooling configurations for both air and liquid cooling solutions. Design and build a custom leading-edge silent operation PC with options for 120/140/200mm cooling fans and liquid cooling support for single, dual and triple radiator applications.

Optimized Silent Operation

For acoustic test, Suppressor F31 was tested in a semi-anechoic chamber which includes anti-vibration, sound-proof, and sound-absorbing effect. Preinstalled sound-damping foams of Suppressor F31 reduce noise and acoustic levels within the entire chassis for extreme silent purpose. Suppressor F31 Acoustic Test Result:

Optimized Cooling Performance

Thermal imaging camera was applied for the temperature test of the chassis. After the removal of all sound-damping covers from the top panel, Suppressor F31 Window dissipates heat more efficiently. The temperature decreases 2.2°C/35.9°F without any sound damping covers.

Advanced Ventilation

The Suppressor F31 Window delivers outstanding cooling performance for DIY/AIO liquid cooling and air cooling systems. With wide top-to-bottom side ventilation grills, air intake is with a single 120mm front fan built-in and includes options for up to (3) 120mm or 140mm front fans combined with (2) bottom mount 140mm fan locations for maximum fan space selection. Dissipate heat properly with (1) rear built-in 120mm fan and (3) sectional top mounts to manage proper air flow in and out.

High-End Complete Solution

The Thermaltake Suppressor F31 Window enables users to build a complete high-end system that supports up to triple 120mm, double 140mm liquid cooling radiators or up to 200mm case fans. With extended graphic card support (up to 360mm), the Suppressor F31 Window simultaneously protects the hardware and increases the CPU’s overclocking potential for users looking to get the most out of their hardware. Most importantly, the Suppressor F31 Window delivers outstanding cooling efficiency, reduced exterior noise and dust signatures for ideal silent operation.

Power Cover Design (Optional)

Power supply placement design is one of the Suppressor F31 unique features. The entire bottom area can be used to reorganize unused cables, which makes for a tidy-looking system. Users can enjoy the freedom of gaining the maximum interior space for advance cooling performance or liquid system build. Furthermore, the PSU cover can hold two additional 2.5” HDD drive bays.

More Information
P/N CA-1E3-00M1WN-00
SERIES Suppressor
CASE TYPE Mid Tower
DIMENSION (H X W X D) 497 x 250 x 515 mm

(19.5 x 9.8 x 20.3 inch)

NET WEIGHT 9.4 kg / 20.7 lb
SIDE PANEL Window
COLOR Exterior & Interior : Black
MATERIAL SPCC
COOLING SYSTEM Front (intake) :
120 x 120 x 25 mm Turbo fan (1000rpm, 16dBA)
Rear (exhaust) :
120 x 120 x 25 mm Turbo fan (1000rpm, 16dBA)
DRIVE BAYS
-ACCESSIBLE
-HIDDEN
2 x 5.25’’

-Accessible : 3 x 3.5’’ or 2.5’’ (HDD Cage)

-Hidden :  3 x 3.5’’ or 2.5’’ (Behind the M/B tray)

EXPANSION SLOTS 8
MOTHERBOARDS 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX)
LCS UPGRADABLE Supports 1/2”、3/8”、1/4” water tube
I/O PORT USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1
PSU Standard PS2 PSU (optional)
FAN SUPPORT Front:2 x 120mm or 2 x 140mm or 1 x 200mm
Top:
3 x 120mm or 3 x 140mm or 2 x 200mm
Rear:
1 x 120mm or 1 x 140mm
Bottom:
2 x 120mm or 2 x 140mm
Left Side (For No Window Side Panel Only):
1 x 120mm or 1 x 140mm
RADIATOR SUPPORT Front:
1 x 360mm or 1 x 280mm
Top:
1 x 360mm or 1 x 280mm
Rear:
1 x 120mm or 1 x 140mm
Bottom:
1 x 120mm or 1 x 140mm
CLEARANCE CPU cooler height limitation:
180mm
VGA length limitation:
278mm(with HDD rack)
420mm(without HDD rack)
PSU length limitation:
180mm (With One Bottom Fan)
220mm (Without Bottom Fan)



Additional information

Weight 26.9 lbs
Dimensions 11.85 × 21.26 in
