Description
Ports & Slots
- 1. USB 3.1 Gen 1 (USB-C, with Power Delivery and DisplayPort Alt Mode)
- 2. USB 3.1 Gen 1 (always on)
- 3. USB 3.1 Gen 1
- 4. HDMI 1.4b
- 5. Headphone / mic combo
- 6. USB 2.0
- 7. RJ45
- 8. Kensington lock slot
Features
Standout performance…
The ThinkPad E14 is equipped with up to 10th Gen Intel® Core i7 processing, plus the option of dual-drive storage. So you can have the power and speed you need to get the job done—wherever you are.
meets exceptional design
At just around twice the thickness of a smartphone, the ThinkPad E14 exudes all the elegance of a premium laptop—without the hefty price tag. It also has an optional fingerprint reader integrated into the power button that lets you fire up and log in at the same time.
Built-in security…
With the ThinkPad E14, you can rest easy knowing that your important data is encrypted via the discrete Trusted Platform Module [dTPM] 2.0 chip. You can also keep the outside world out thanks to ThinkShutter (optional), a physical cover to close the webcam when you’re not using it.
with super-fast connectivity
A full-function USB-C port makes everything a breeze—from audio to video, from data transfers to recharging. What’s more, video conference calls fly by thanks to the Skype for Business-certified microphone. With 802.11AC WiFi 5 (2 x 2) you’ll enjoy fast and speedy connectivity.
Fully immersive…
Experience crystal-clear visuals and truly vivid colours on the 14”, anti-glare FHD display with IPS wide-angle viewing (optional). In addition, the sound on the ThinkPad E14 packs a real punch—through Dolby Audio™ and premium stereo speakers by Harman Kardon®.
& totally reliable
MIL-SPEC tested to withstand the most rugged, harshest of environments, the ThinkPad E14 won’t let you down. Not only can it perform everywhere from the freezing cold to a hot desert, it can also handle accidental knocks, drops, and even spills.
Specs
| PERFORMANCE | |
| Processor |
Intel® Core™ i7-10510U (4C / 8T, 1.8 / 4.9GHz, 8MB)
|
| Graphics |
Integrated Intel® UHD Graphics
|
| Chipset |
Intel® SoC Platform
|
| Memory |
1x 8GB SO-DIMM DDR4-2666
|
| Memory Slots |
One DDR4 SO-DIMM slot
|
| Max Memory |
Up to 16GB DDR4-2666
|
| Storage |
256GB SSD M.2 2242 PCIe® 3.0×2 NVMe®
|
| Optane Memory |
None
|
| Storage Support |
Up to two drives, 1x 2.5″ HDD + 1x M.2 SSD • 2.5″ HDD up to 2TB • M.2 2242 SSD up to 512GB • M.2 2280 SSD up to 1TB • Optional Intel® Optane™ Memory or Optane Memory Integrated with SSD, M.2
|
| Optical |
None
|
| Audio Chip |
High Definition (HD) Audio, Synaptic® CX11880 codec
|
| Speakers |
Stereo speakers, 2W x2, Dolby® Advanced Audio
|
| Camera |
720p with ThinkShutter
|
| Microphone |
2x, Array
|
| Battery |
Integrated 45Wh
|
| Power Adapter |
65W USB-C® (2-pin)
|
| DESIGN | |
| Display |
14″ FHD (1920×1080) IPS 250nits Anti-glare
|
| Touchscreen |
None
|
| Keyboard |
Non-backlit, English
|
| Case Color |
Black
|
| Case Material |
Aluminium (Top), PC + ABS (Bottom)
|
| Dimensions (WxDxH) |
325 x 232 x 18.9 mm (12.8 x 9.13 x 0.74 inches)
|
| Weight |
1.69 kg (3.73 lbs)
|
| SOFTWARE | |
| Operating System |
Windows® 10 Pro 64, English
|
| Bundled Software |
None
|
| CONNECTIVITY | |
| Ethernet |
100/1000M
|
| WLAN + Bluetooth |
RTL8822CE 11ac, 2×2 + BT5.0
|
| WWAN |
None
|
| SIM Card |
None
|
| NFC |
None
|
| Standard Ports |
|
| Monitor Cable |
None
|
| SECURITY & PRIVACY | |
| Smart Card Reader |
None
|
| Security Chip |
Discrete TPM 2.0
|
| Fingerprint Reader |
Touch Style
|
| Physical Locks |
Kensington® Security Slot™
|
| Other Security |
ThinkShutter camera cover
|
| MANAGEABILITY | |
| System Management |
None
|
| SERVICE | |
| Base Warranty |
1-year, Depot
|
| Included Upgrade |
None
|
| ACCESSORIES | |
| Bundled Accessories |
None
|
| CERTIFICATIONS | |
| Green Certifications |
|
| Mil-Spec Test |
MIL-STD-810G military test passed
|
