Description
Powerful and high value
An ideal first server for your growing business, remote/branch office, or retail location, the Lenovo ThinkSystem ST50 V2 enhanced performance increases productivity.
The ThinkSystem ST50 V2 boasts the improved operation of the latest Intel® Xeon® E-2300 processors. With a 17% increase in performance the ThinkSystem ST50 V2 offers professional-level capabilities at an entry-level price-point. High value versus a workstation with the benefits of a resilient server.
Flexible
The ThinkSystem ST50 V2 adds value and flexibility for your growing business by providing support for three PCIe slots with support of single GPU, and various high bandwidth network adapters along with an array of compatible storage drives. It can be scaled to fit your growing business, provides high reliability, and uses common components to reduce costs.
Lenovo’s XClarity (USB) provisioning manager enables easy setup and firmware upgrades while Intel Active Management Technology (AMT)saves time and reduces costs by monitoring system health and preventing data disruption.
Energy-efficient, quiet, yet powerful
Designed for discretion the ST50 V2’s compact size, flexible mounting options, and whisper-quiet acoustics allow it to be placed in an office environment without disruption
It´s energy-efficient with a TDP of no more than 95W and supports up to 8 core performance. Providing optimal performance for increased productivity and energy cost-savings.
System Specs
| Form Factor / Dimensions | 1-Socket (1S) Entry Tower, 17 liter chassis, 170 mm (6.7 in.), height: 376 mm (14.8 in.), depth: 316 mm (12.4 in.) |
| Processor | Intel® Xeon® E‑2356G, 6 Cores / 12 Threads, 3.2 GHz, up to 5.0 GHz, 80W TDP, 12 MB Cache |
| Memory | 16GB DDR4 ECC UDIMM (up to 128GB supported) |
| RAID Support | Intel® VROC software RAID; hardware RAID optional |
| EXPANSION | |
| Expansion Slots | 1x PCIe Gen4 x16, 1x PCIe Gen3 x1, 1x PCIe Gen3 x4 |
| Drive Bays | 2x 3.5″ HDDs (1 pre-installed), 1x 2.5″ HDD, 1x NVMe M.2 SSD, 1x Slim ODD bay |
| CONNECTIVITY | |
| I/O Ports (Front) | 2x USB 3.2 G2 (10Gb) ports, 2x USB 3.2 G1 (5Gb) ports, 1x USB 3.2 G2 Type C (10Gb) port |
| I/O Ports (Rear) | 4x USB 3.2 G1 (5Gb) ports;1x Serial port; 2x DisplayPort ports; 1x audio line out (for Microsoft client OS only) |
| Network Interface | 1x 1GbE (Intel® i219-LM) |
| POWER | |
| Power Supply | 1x Fixed power supply, Choose from 300W Gold or 500W Platinum |
| SECURITY & MANAGEMENT | |
| Management & Security | Intel® AMT, Lenovo XClarity Provisioning Manager (USB), TPM 2.0 |
| SOFTWARE | |
| Operating System | Supports Microsoft, SUSE, Red Hat, VMware vSphere, CentOS |
| SERVICE | |
| Warranty | 1- and 3-year customer replaceable unit and onsite service, next business day 9×5 |
