Description
100% RAM CLEARANCE
X-VENTS DESIGN
Positioned in a 45-degree angle and surrounding the heatpipe, each fin-blade features X-shaped vents that create areas of high and low air pressure, resulting in several controlled vortices. These small and chaotic turbulences produce strong gusts that reduce overall airflow but improve airflow where it matters the most – next to the heatpipes
DIRECT CONTACT TECHNOLOGY
4 heatpipes with Direct Contact Technology creates a sleek contact surface area for maximize heat dissipation
SICKLEFLOW 120 FAN
Newly Optimized blade design with updated curve that provides best balance between airflow and static pressure to take the heat away while remain extremely silence.
QUIET OPERATION
Specs
| Product Line: | Hyper 212 EVO V2 |
| Product Name: | HYPER 212 EVO V2 Cooling Fan/Heatsink |
| Product Type: | Cooling Fan/Heatsink |
| Fan Information | |
| Number of Fans: | 1 |
| Fan Speed (Max): | 1800 rpm |
| Maximum Airflow: | 1755.6 L/min |
| Noise Levels: | 27 dB(A) |
| Fan Life: | 18.3 Year |
| Heatsink Information | |
| Compatible Processor Socket: | Socket R4 LGA-2066, Socket LGA 2011-v3, Socket R LGA-2011, Socket LGA-1200, Socket B LGA-1366, Socket H LGA-1156, Socket H2 LGA-1155, Socket H4 LGA-1151, Socket H3 LGA-1150, Socket T LGA-775, Socket AM4, Socket AM3+, Socket AM3 PGA-941, Socket AM2+ PGA-940, Socket AM2 PGA-940, Socket FM2+, Socket FM2, Socket FM1 |
| Physical Characteristics | |
| Material: | Copper Heat Pipe, Aluminum Fin |
| Heatsink Height: | 6.10″ (155 mm) |
| Heatsink Width: | 4.72″ (120 mm) |
| Heatsink Depth: | 3.15″ (80 mm) |
| Fan Height: | 4.72″ (120 mm) |
| Fan Width: | 4.72″ (120 mm) |
| Fan Depth: | 0.98″ (25 mm) |
| Weight (Approximate): | 760 g |
| Miscellaneous | |
| Application/Usage: | Processor |
| Warranty | |
| Limited Warranty: | 2 Year |
